X10SDV-F - Supermicro Intel Xeon D-1541 mini-ATX System Board (Motherboard) Socket FCBGA 1667

1. Processor Socket Type: FCBGA 1667
2. Processor Type: Intel Xeon D-1541
3. Number of Memory Slots: 4 x 288-pin DDR4 DIMM
4. Maximum Memory Supported: 128GB
5. Memory Standard: DDR4 2133 MHz ECC RDIMM and LRDIMM
6. SATA 3.0 Ports: 6 x SATA3 6Gbps
7. M.2 Slots: 1 x M.2 (PCI-E 3.0 x4, NVMe)
8. LAN Ports: 2 x 10GBase-T, 2 x GbE
9. USB Ports: 2 x USB 3.0, 4 x USB 2.0
10. Expansion Slots: 1 x PCI-E 3.0 x16, 1 x Mini-PCI-E
11. Power Connectors: 1 x 24-pin ATX main power connector, 1 x 8-pin ATX 12V power connector
12. Form Factor: Mini-ATX

Notes:
1. This motherboard is designed for use in small form factor servers and embedded systems.
2. The Intel Xeon D-1541 processor is a low power, high performance chip designed for server applications.
3. The dual 10GBase-T LAN ports provide high speed networking capabilities for demanding applications.
