EMC 100-560-148 | DS-16B3 (SilkWorm 3850) 16-Port Fibre Channel Switch

1. Number of Ports: 16
2. Fibre Channel Speed: 16 Gbps
3. Supported Protocols: FC-AL, FC-AL-2, FC-FG, FC-FLA, FC-GS-2, FC-PH, FC-PH-2, FC-PH-3, FC-PLDA, FC-SW-2, FC-SW-3, FC-Tape, FC-VI, FC-SP, FCP-2, FCP-3
4. Max Frame Size: 2112 bytes
5. Switching Bandwidth: 512 Gbps
6. Buffer Credits: 2048
7. Fabric OS: v8.2.1b
8. Power Consumption: 110W
9. Input Voltage: 100-240V AC
10. Dimensions (HxWxD): 1.7 x 16.9 x 12.5 in
11. Weight: 8.6 lbs
12. Rack Mountable: Yes

Notes:
1. The EMC DS-16B3 switch is designed for high-performance, low-latency Fibre Channel storage networks.
2. The switch supports advanced features such as ISL Trunking, Virtual Fabrics, and Quality of Service (QoS).
3. With its compact size and rack-mountable design, the DS-16B3 is ideal for data centers and other enterprise environments where space is at a premium.
