Cisco 15454-32-DMX-RF | 32Channel Demultiplexer Module

1. Dimensions: 1.72 x 14.17 x 16.89 inches
2. Weight: 5.5 lbs
3. Power Consumption: 25 watts
4. Operating Temperature: 23°F to 131°F
5. Storage Temperature: -40°F to 185°F
6. Humidity: 5% to 95% non-condensing
7. Optical Connectors: SC/APC
8. Maximum Input Power: +23 dBm
9. Wavelength Range: 1528.77 nm to 1563.86 nm
10. Channel Spacing: 100 GHz
11. Insertion Loss: 4.5 dB typical, 6.0 dB maximum
12. Return Loss: 45 dB typical

Notes:
1. This module is designed for use with Cisco ONS 15454 Multiservice Transport Platform.
2. It supports up to 32 channels of demultiplexing.
3. The module can be hot-swapped without affecting the system.
