15454-AD-2C47.7-RF - Cisco OADM 2-Channel Multiplexer Module

Here are 12 technical specs for the Cisco OADM 2-Channel Multiplexer Module:

1. Channel Spacing: 100 GHz
2. Wavelength Range: 1528.77 nm to 1568.77 nm
3. Insertion Loss: 4.5 dB typical, 6.0 dB maximum
4. Return Loss: 45 dB minimum
5. Crosstalk: -25 dB minimum
6. Polarization Dependent Loss (PDL): 0.2 dB maximum
7. Polarization Mode Dispersion (PMD): 0.5 ps maximum
8. Operating Temperature Range: -5°C to 55°C
9. Storage Temperature Range: -40°C to 85°C
10. Humidity Range: 5% to 95% non-condensing
11. Dimensions (H x W x D): 1.23 x 8.72 x 9.00 in. (3.12 x 22.15 x 22.86 cm)
12. Weight: 1.5 lbs (0.68 kg)

Helpful notes:
1. The Cisco OADM 2-Channel Multiplexer Module is designed for use in dense wavelength-division multiplexing (DWDM) systems.
2. This module can be used in a variety of applications, including metropolitan area networks (MANs) and long-haul networks.
3. The module is hot-swappable, allowing for easy installation and replacement without disrupting network traffic.
