Cisco 15454-OPT-BST= | 15454 Optical Booster Amplifier Module

1. Optical Wavelength: C Band (1528.77 to 1563.86 nm)
2. Maximum Output Power: 13 dBm
3. Gain: 20 dB
4. Noise Figure: 5.5 dB
5. Input Power Range: -20 dBm to +5 dBm
6. Input and Output Connectors: SC/APC
7. Power Consumption: 12 W
8. Operating Temperature Range: -5°C to 55°C
9. Storage Temperature Range: -40°C to 85°C
10. Humidity Range: 5% to 95% non-condensing
11. Dimensions (H x W x D): 1.25 x 10.5 x 7.25 inches
12. Weight: 2.5 lbs

Notes:
1. The 15454-OPT-BST= is a plug-in module that can be easily installed in the Cisco ONS 15454 MSTP platform.
2. The module provides optical amplification and extends the reach of optical signals in long-haul and ultra-long-haul networks.
3. The module is hot-swappable, allowing for easy replacement without disrupting the network.
