Sun 371-3662-01 | SATA To Fiber Channel 3.5-inch HDD Interface Board

Here are the technical specifications for the Sun SATA to Fiber Channel 3.5-inch HDD Interface Board:

1. Interface Type: SATA to Fiber Channel
2. Supported Devices: 3.5-inch HDDs
3. Data Transfer Rate: Up to 4 Gbps
4. Form Factor: Plug-in module
5. Compatible Servers: Sun Fire X4100, X4200, X4500, X4600, X2100 M2, X2200 M2, and X4200 M2
6. RAID Levels Supported: RAID 0, RAID 1, and RAID 1E
7. Hot-Swap Support: Yes
8. Cache Memory Size: 256 MB
9. Operating Temperature: 0°C to 55°C
10. Storage Temperature: -40°C to 70°C
11. Operating Humidity: 10% to 90% non-condensing
12. Storage Humidity: 5% to 95% non-condensing

Helpful notes:
1. This interface board is designed to provide high-speed data transfer between SATA drives and Fiber Channel networks.
2. The board supports hot-swapping, allowing for easy replacement of failed drives without shutting down the system.
3. The 256 MB cache memory helps to improve system performance by reducing latency and increasing data throughput.
