HP 448316 001 | LSI 8 Port SAS RAID Controller

1. Interface Type: PCI Express
2. Data Transfer Rate: 3 Gbps
3. RAID Levels: 0, 1, 5, 6, 10, 50, 60
4. Cache Memory: 256 MB DDR2 SDRAM
5. Supported Devices: SAS/SATA
6. Max Storage Devices Qty: 122
7. Processor: LSI LSISAS1078
8. Form Factor: Plug-in Card
9. Operating Temperature: 0°C to 55°C
10. Operating Humidity: 5% to 90%
11. OS Required: Microsoft Windows Server 2003, Red Hat Enterprise Linux, SuSE Linux Enterprise Server, Microsoft Windows Server 2008, VMware ESX Server
12. Dimensions (WxDxH): 6.6 cm x 16.8 cm x 1.6 cm

Notes:
1. This controller supports advanced data protection features such as RAID 6 and 60.
2. The 256 MB DDR2 SDRAM cache memory ensures faster data transfer rates.
3. Compatible with a wide range of operating systems, including VMware ESX Server.
