Brocade 57-1000263-01 | 40Gb/s 40GBase-LR4 Single-Mode Fibre 1310nm 10km LC Connector QSFP+ Transceiver Module

Here are the technical specifications for the Brocade 40Gbps 40GBase-LR4 Single-mode Fibre 10km 1310nm LC Connector QSFP+ Transceiver Module:

1. Data Rate: 40Gbps
2. Connector Type: LC
3. Wavelength: 1310nm
4. Cable Type: Single-mode Fiber
5. Max Distance: 10km
6. Operating Temperature: 0°C to 70°C
7. Voltage Supply: 3.3V
8. Power Consumption: 3.5W
9. Digital Diagnostics Monitoring (DDM): Yes
10. Hot Pluggable: Yes
11. Compliance: IEEE 802.3ba, QSFP+ MSA
12. Form Factor: QSFP+

Helpful Notes:
1. The Brocade 40Gbps 40GBase-LR4 Single-mode Fibre 10km 1310nm LC Connector QSFP+ Transceiver Module is designed for long-range data transmission over single-mode fiber optic cables.
2. This transceiver module is hot-pluggable, which means it can be inserted or removed from a powered-on device without causing damage to the equipment.
3. The Digital Diagnostics Monitoring (DDM) feature allows for real-time monitoring of the transceiver module's performance, including temperature, voltage, and optical power levels.
