657131-001 - HP PCI Express x8 Flex-10 10GB 2-Port 530M Mezzanine Network Adapter

Here are 12 technical specifications for the HP PCI Express x8 Flex-10 10GB 2-Port 530M Mezzanine Network Adapter:

1. Interface Type: PCI Express x8
2. Data Transfer Rate: 10 Gbps
3. Number of Ports: 2
4. Connectivity Technology: Wired
5. Cabling Type: Ethernet 10GBase-KX4
6. Processor: 1 x BCM57712 - Broadcom
7. Form Factor: Plug-in card - low profile
8. Compatible Slots: 1 x PCI Express x8
9. Networking Standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ap
10. Features: VLAN support, Quality of Service (QoS), Jumbo Frames support, PXE support, Large Send Offload (LSO), Large Receive Offload (LRO), Receive Side Scaling (RSS), TCP/IP checksum offload, MSI-X support, Virtual Machine Device Queues (VMDq)
11. OS Required: Microsoft Windows Server 2008, Red Hat Enterprise Linux 5, Red Hat Enterprise Linux 6, SuSE Linux Enterprise Server 10, SuSE Linux Enterprise Server 11, VMware ESX 4.0, VMware ESXi 4.1, VMware ESXi 5.0
12. Dimensions (WxDxH): 6.6 cm x 16.8 cm x 1.5 cm

Helpful notes:
1. This network adapter is designed for use in HP BladeSystem c-Class enclosures.
2. The Flex-10 technology allows for the adapter to be configured to support up to eight NICs.
3. This adapter is compatible with a variety of operating systems, including Windows Server, Linux, and VMware.
