780018-S01 - HP ProLiant DL360 G9 Intel Xeon E5-2620v3 6-Core 2.4GHz CPU 16GB RAM Server

Key Features :
Processor Type: Intel Xeon E5-2620v3/2.4 Ghz
Multi-core Technology: 6-core
64-bit Computing: Yes
Installed Processor Qty: 1
Max Supported Processor Qty: 2
Chipset Model: C610
Upgradability: Upgradable
Cache Memory Type: L3 Cache
Installed Size: 15 Mb
Cache Per Processor: 15 Mb
Hard Drive: None

Memory:
Installed Ram Size: 16gb
Max Supported Size : 384 Gb
Technology: Ddr4 Sdram - Advanced Ecc
Memory Speed: 1600 Mhz
Memory Specification Compliance: Pc4-17000
Form Factor: Dimm 288-pin
Features: Registered, Online Spare Memory, Quad Channel Memory Architecture, Hp Smartmemory
Configuration Features: 2x 8gb
Ram Supported:
Pc4-17000 - 768 Gb - Load-reduced
Pc4-17000 - 384 Gb - Registered

Storage Controllers :
Storage Controller Type: 1 X Raid - Plug-in Card - Pci Express 3.0 X8
Controller Interface Type: Serial Ata-600 / Sas 3.0
Storage Controller Name: Hp H240ar Smart Host Bus Adapter
Channel Qty : 8
Raid Level: Raid 0, Raid 1, Raid 5

Display & Graphics :
Graphics Controller Type: Integrated
Graphics Processor: Matrox G200
Video Interfaces : Vga

Networking :
Ethernet Ports: 8x Gigabit Ethernet
Ethernet Controller(s): Hp 331i, Hp 331flr
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller: Integrated Lights-out 4
Features: Wake On Lan (wol), Pxe Support
Compliant Standards: Ieee 802.3, Ieee 802.3u, Ieee 802.3ab

Connectivity :
Expansion Bays Total (free):
8 ( 8 ) X Hot-swap - 2.5inch Sff
1 ( 1 ) X External

Interfaces & Ports:
1 X Vga
1 X Serial
8 X Lan (gigabit Ethernet)
1 X Hp Ilo
5 X Usb 3.0 ( 1 Front, 2 Rear, 2 Internal )

Power Description:
Device Type: Power Supply - Hot-plug
Power Redundancy: Yes
Power Redundancy Scheme: 1+1
Installed Qty: 2
Max Supported Qty: 2
Voltage Required: Ac 120/230 V ( 50/60 Hz )
Power Provided: 500 Watt
80 Plus Certification : 80 Plus Platinum

Dimensions :
Width : 17.1 In
Depth : 27.2 In
Height: 1.7 In
