8677-HC1 - IBM BladeCenter E 8677 Chassis

1. Dimensions: 7.1 x 17.6 x 29.7 inches
2. Weight: 53.8 pounds
3. Power supply: 2000W AC
4. Fans: 6 hot-swap redundant fans
5. Blade bays: 14 hot-swap bays
6. Management module: Integrated Advanced Management Module (AMM)
7. Supported blade servers: IBM BladeCenter HS23, HS23E, HS22, HS22V, HS21, HS21XM, LS22, LS42, JS22, JS23, JS43, PS700, PS701, PS702, PS703, PS704, PS705, PS706
8. Networking: Integrated 10/100/1000 Ethernet switch module
9. Expansion slots: 2 high-speed I/O bays for additional network or storage connectivity
10. Compatibility: Compatible with IBM BladeCenter H, HT, S, and T chassis
11. Operating temperature: 10°C to 35°C (50°F to 95°F)
12. Operating humidity: 8% to 80% non-condensing

Notes:
1. The integrated AMM provides remote management capabilities, including KVM over IP and virtual media support.
2. The 10/100/1000 Ethernet switch module supports up to 14 external Ethernet ports.
3. The BladeCenter E 8677 chassis is designed for high-density computing environments and can support up to 14 blade servers in a single chassis.
