HP 868246-001 | SPS-EL1000 PxI Backplane

Here are 12 technical specifications for the HP SPS-EL1000 PxI Backplane:

1. Form Factor: PXI
2. Number of Slots: 14
3. Data Bus Width: 32-bit
4. Trigger Bus: PXI_STAR
5. Clock Bus: PXI_CLK10
6. Power Requirements: +3.3V, +5V, -12V, +12V
7. Maximum Power Consumption: 20W
8. Operating Temperature Range: 0°C to 55°C
9. Dimensions: 233.68mm x 177.8mm x 20.32mm
10. Weight: 0.36 kg
11. RoHS Compliance: Yes
12. Compatibility: Compatible with HP EL1000 Embedded Controller

Helpful notes:
1. The HP SPS-EL1000 PxI Backplane is designed for use in PXI-based test and measurement systems.
2. It allows for up to 14 PXI modules to be inserted and interconnected within a single chassis.
3. The backplane provides a high-speed data bus, trigger bus, and clock bus for synchronization and communication between modules.
