ACX1100-AC - Juniper ACX1100 Universal Metro Router

1. Dimensions: 1.73 x 17.4 x 10.6 inches
2. Weight: 7.72 lbs
3. Power supply: AC or DC
4. Power consumption: 40W (typical)
5. Operating temperature: 0°C to 40°C
6. Storage temperature: -40°C to 70°C
7. Humidity: 5% to 95% non-condensing
8. Routing protocols: OSPF, BGP, IS-IS, RIP, PIM-SM, PIM-SSM, PIM-DM, IGMP, MLD, RSVP-TE, LDP, BFD, VRRP, L2VPN, L3VPN
9. Interfaces: 8 x 10/100/1000 Mbps Ethernet ports, 4 x GbE SFP ports, 2 x 10 GbE SFP+ ports
10. Forwarding performance: 4 Gbps
11. Maximum concurrent sessions: 64,000
12. Jumbo frames: up to 9192 bytes

Notes:
1. The ACX1100 is a cost-effective solution for service providers to deliver high-performance Ethernet services.
2. The router supports MPLS, VPLS, and EVPN, making it ideal for carrier Ethernet and mobile backhaul applications.
3. The compact form factor and low power consumption make it suitable for deployment in space-constrained environments.
