N2K-C2248PQ-10GE | Cisco Nexus 2248PQ 48-Ports 10/100/1000 Fabric Extender Expansion Module

Here are 12 technical specifications for the Cisco Nexus 2248PQ 10GE Fabric Extender Expansion Module:

1. Interface: 48 x 1/10 Gigabit Ethernet/FCoE SFP+ ports and 4 QSFP+ ports
2. Data Transfer Rate: 10 Gbps
3. Switching Capacity: 960 Gbps
4. Forwarding Rate: 714 Mpps
5. Jumbo Frame Support: 9216 bytes
6. VLAN Support: 4096 active VLANs
7. Maximum MTBF: 264,580 hours
8. Power Consumption: 320W maximum
9. Operating Temperature: 32°F to 104°F (0°C to 40°C)
10. Storage Temperature: -40°F to 158°F (-40°C to 70°C)
11. Dimensions: 1.7 x 16.9 x 17.3 inches (4.3 x 43 x 44 cm)
12. Weight: 10.8 lbs (4.9 kg)

Helpful notes:
1. The Cisco Nexus 2248PQ 10GE Fabric Extender Expansion Module is designed to provide high-performance connectivity for data center servers.
2. The module supports both Ethernet and Fibre Channel over Ethernet (FCoE) protocols.
3. The QSFP+ ports can be used for either 40 Gigabit Ethernet or 4 x 10 Gigabit Ethernet connectivity.
