N9K-C93180YC-EX - Cisco One Nexus 9300 48-Port x 1/10/25Gb/s LAN SFP+ Layer3 1U Rack-Mountable Switch

Key Features :
Device Type : Switch - 48 Ports - L3
Enclosure Type : Rack-mountable 1u
Subtype : 25 Gigabit Ethernet
Ports : 48 X 1/10/25 Gigabit Sfp+ + 6 X 40/100 Gigabit Qsfp+
Performance : Bandwidth: 3.6 Tbps ¦ Active Span Sessions: 4
Capacity : Multiple Spanning Tree Protocol Instances: 64 ¦ Hsrp Groups: 490 ¦ Per Vlan Rapid Spanning Tree Instances: 4000 ¦ Maximum Number Of Links In A Port Channel: 32 ¦ Maximum Number Of Port Channels: 512 ¦ Ecmp Paths: 64 ¦ Virtual Routing And Forwarding (vrf) Instances: 1000 ¦ Vlans Supported: 4096 ¦ Acl Entries (egress): 2000 ¦ Acl Entries (ingress): 4000 ¦ Igmp Snooping Groups: 8000 ¦ Multicast Routes: 8000
Mac Address Table Size : 512k Entries
Routing Protocol : Ospf, Rip, Rip-2, Bgp, Eigrp, Hsrp, Pim-sm, Msdp, Ecmp, Mpls
Features : Layer 3 Switching, High Availability, Hot Swappable 4 Fans, Virtual Portchannel (vpc) Technology, In-service Software Upgrade (issu), Npv Gateway Mode, Virtual Extensible Lan (vxlan), Source-specific Multicast (ssm), Ethernet Virtual Private Network (evpn), 40mb System Buffer
Ram : 16 Gb
Built-in Devices : 64 Gb Ssd

Connectivity :
interfaces :
48 X 1/10/25gbit Lan Sfp+ Downlink
6 X 100gbit/40gbit Lan Qsfp28 Uplink
1 X Management Rj-45
1 X Management Sfp+
1 X Usb
1 X Serial (rs-232)
