Sick WLL180T-F232 | Fiber-Optic Sensors

Here are the technical specifications for the Sick Fiber-Optic Sensor WLL180T-F232:

- Sensing range: 0 to 100 mm
- Light source: LED, 660 nm (red)
- Fiber diameter: 2.2 mm
- Operating voltage: 10 to 30 V DC
- Output: NPN, normally open
- Response time: 0.5 ms
- Housing material: Nickel-plated brass
- Operating temperature: -25 to 55 °C

Helpful notes:
- The WLL180T-F232 is ideal for detecting small objects in tight spaces.
- Its fast response time makes it suitable for high-speed applications.
- The nickel-plated brass housing provides durability and resistance to corrosion.
