HP J9307A | PoE+ zl Switching Expansion Module

1. Ports: 8 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+), Media Type: Auto-MDIX, Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
2. PoE capability: 30 W per port, maximum 144 W per module
3. Switching capacity: 16 Gbps
4. Throughput: up to 11.9 million pps
5. Latency: < 3.5 µs (64-byte packets)
6. VLAN support: 4096 VLAN IDs
7. Jumbo frame support: up to 9220 bytes
8. Dimensions (W x D x H): 8.13 x 10.25 x 1.75 in
9. Weight: 2.75 lb
10. Operating temperature: 32°F to 131°F (0°C to 55°C)
11. Operating humidity: 15% to 95%, noncondensing
12. Power consumption: 150 W maximum

Notes:
1. This module is compatible with HP E5400 and E8200 series switches.
2. The PoE+ capability allows for easier deployment of power-hungry devices such as IP cameras and wireless access points.
3. The jumbo frame support can help improve network performance by reducing the number of packets needed to transmit large files.
